Audi 12.3" Touchscreen for MMI 3G — Wireless CarPlay

12.3-INCH TOUCHSCREEN WITH WIRELESS APPLE CARPLAY AND ANDROID AUTO FOR AUDI WITH MMI 3G / 3G+: 2009 - 2016 A4, A5 AND Q5 WITH FACTORY NAVIGATION AND 2012 - 2015 A6. REPLACES THE FACTORY SCREEN.

FITMENT — LEFT-HAND DRIVE CARS

One listing for the models below. Each model uses its own mounting base and harness, so we match the kit to your car by VIN.

• Audi A4 B8 / B8.5 (2009-2016) with factory navigation (MMI 3G / 3G+)
• Audi A5 (2009-2016) with factory navigation (MMI 3G / 3G+)
• Audi Q5 8R (2009-2016) with factory navigation (MMI 3G / 3G+)
• Audi A6 C7 (2012-2015) with MMI 3G+

HOW TO TELL CONCERT / SYMPHONY FROM MMI 3G

• Concert or Symphony: the radio in the center stack has its own small display, and there is no MMI controller (a rotary knob with buttons around it) on the center console
• MMI 3G / 3G+: a separate color screen sits in the dash and an MMI rotary knob with buttons is on the center console behind the gear lever
• Not sure which one you have? Email a photo of the whole dashboard, with the radio and screen in view, to info@carsgadget.com and we tell you which kit fits

FEATURES

• 12.3-inch touchscreen, Linux system
• Apple CarPlay — wireless or wired connection
• Android Auto — wireless or wired connection
• AirPlay screen mirroring for iPhone
• Android screen mirroring
• Bluetooth hands-free calls and Bluetooth music
• Option to keep using the factory car Bluetooth
• USB media player
• Original car menu shown on the new screen
• Backup camera input (RCA) and front camera view
• Brightness, contrast, saturation and backlight settings
• Separate volume for media, calls, voice and navigation; microphone gain; EQ settings
• Wi-Fi used only to connect the phone — no internet access

INSTALLATION NOTES

• The factory screen is removed and the 12.3-inch display mounts in its place on the base made for your model
• The factory system stays in the car; its menu opens on the new screen
• The supplied harness set connects the display to the factory system; the parts differ by model
• On A4 / A5 / Q5 the factory hazard light switch connects through the supplied adapter
• After install, set the original screen resolution in the settings menu to match your factory screen
• The harness has an RCA video input for a backup camera; a camera is not included

CHECK YOUR SYSTEM BEFORE ORDERING

• MMI 3G / 3G+ only. A4 / A5 / Q5 without factory navigation (Concert or Symphony radio) need our 12.3" Touchscreen for Concert / Symphony radio
• A6 C7: 2012-2015 cars with MMI 3G+ only; 2016 and later A6 are not covered
• Model years: A4 / A5 / Q5 2009-2016, A6 2012-2015. Other model years are not covered by this listing
• Left-hand drive cars only
• Enter your VIN on this page before ordering, so we can match the kit to your car

This item ships directly from the manufacturer in about 7–14 days. The mounting base and harness differ by model, so enter your VIN in the box on this page before you add the kit to the cart — it goes with your order, and we match the kit to your car before it ships. Questions before you buy? Email info@carsgadget.com

• 12.3-inch touchscreen display
• Mounting base made for your model
• Harness set made for your model that connects the display to the factory system
• A4 / A5 / Q5: hazard light switch adapter
• 2 x USB cables
• RCA video input cable for a backup camera
• Microphone
• Backup camera is not included — add one below

One kit covers the models in the description. The bracket and harness differ by model, so enter your VIN on this page before you add it to the cart: the VIN goes with your order and we match the kit to your car before it ships.

Ask before you buy

1. 1
   Check your system. The description lists the head unit and the models this screen fits.
2. 2
   Enter your VIN. Use the VIN box on this page before you add the kit to the cart. It goes with your order, and we match the bracket and harness to your car.
3. 3
   Order. The kit ships from the manufacturer in about 7–14 days. US shipping is free.
4. 4
   Install it. The factory screen comes out and the new display mounts in its place; the install notes in the description list each step. Any car audio shop can fit it.
